4-Seat Electric Golf Cart – 4+0 & 2+2 Layouts Available | 48V/72V Lithium
Sun-Cart‘s 4-seat electric golf cart offers flexible seating configurations to meet your specific needs. Choose between 4+0 layout (four forward-facing seats) for standard passenger transport, or 2+2 layout (two forward-facing + two rear-facing) for social, family, or commercial applications where face-to-face interaction is desired. Measuring from 3,200mm to 3,650mm in length depending on configuration, both layouts feature automotive-grade LiFePO₄ battery (2,000+ cycles, 5-year warranty), a 5kW AC motor (same supplier as Toyota), and a smart FOC controller with CAN bus diagnostics. Fully customizable — choose any color, add your logo, and select accessories. With US-based inventory, delivery is fast and support is local.
4+0 Layout
2+2 Layout
Two Seating Layouts – 4+0 or 2+2
Choose standard forward-facing for efficiency or face-to-face for social interaction. Perfect for families, tours, and commercial shuttles.
5-Year Warranty LiFePO₄ Battery
2,000+ cycles, zero maintenance, IP54 waterproof. Lasts 8-10 years — 4x longer than lead-acid.
48V or 72V Power Options
48V for flat terrain (40-50 miles range). 72V for hills and heavy loads (50-65 miles range).
5kW AC Motor
High torque, ultra-quiet (<65dB), zero brush maintenance.
FOC Smart Controller
Smooth acceleration, CAN bus diagnostics, anti-rollback, and programmable speed limits for LSV compliance.
US Warehouse Stock & 5-Year Warranty
3-7 day delivery for in-stock models. US-based support with 24/7 technical assistance.
Full Customization – Any Color, Any Logo
Choose any Pantone color, add your logo (silk screen or metal badge), custom seat upholstery, and accessories. Free digital proof within 2-3 days.
OEM & ODM Available
From color matching to complete vehicle modifications (cargo bed, patrol lights, medical conversions), we build to your specifications. Low MOQ.
| Parameter | 4+0 Layout (Standard) | 2+2 Layout (Face-to-Face) |
|---|---|---|
| Seats | 4 (4 forward-facing for 4+0 / 2 forward + 2 rear-facing for 2+2) | |
| Dimensions (L×W×H) | 3,200 × 1,150 × 1,870 mm | 3,650 × 1,250 × 1,870 mm |
| Wheelbase | 2,440 mm | |
| Net Weight | 460 kg (1,014 lbs) | 495 kg (1,091 lbs) |
| Gross Weight | 530 kg (1,168 lbs) | 570 kg (1,256 lbs) |
| Payload Capacity | 600-800 lbs | |
| Battery Type | LiFePO₄ (Lithium Iron Phosphate) | |
| Battery Capacity (48V) | 130Ah | |
| Battery Capacity (72V) | 105Ah | |
| Battery Warranty | 5 years | |
| Motor Type | 5kW AC motor (same supplier as Toyota) | |
| Top Speed (48V) | 15-20 mph (25-32 km/h) | |
| Top Speed (72V) | 20-25 mph (32-40 km/h) | |
| Range (48V) | 40-50 miles (65-80 km) | |
| Range (72V) | 50-65 miles (80-105 km) | |
| Gradeability (48V) | 25% | |
| Gradeability (72V) | 30% | |
| Charging Time | 8-10 hours | |
| Brake System | Hydraulic front disc / rear drum | |
| Tires | 215/35-12 | |
| Turning Radius | ≤5.5 m | ≤6.0 m |
| Protection Rating | IP54 | |
Application Scenario
Application Scenario
| Application Scenario | Recommended Layout | Description |
|---|---|---|
| 🏠 Family Outings | 2+2 Layout | Face-to-face seating for family interaction. Children can face parents. Perfect for neighborhood cruising, park visits, and short family trips. |
| 🏨 Resorts & Hotels | 4+0 Layout | Standard passenger layout. Efficiently shuttles guests between villas, pools, restaurants, and beaches. Carries 4 guests plus luggage. |
| 🗺️ Tourist Attractions | 2+2 Layout | Ideal for sightseeing tours. Passengers can talk face-to-face. Great for group travel — guides can interact naturally with visitors. |
| 🏘️ Gated Communities | 4+0 Layout | Efficient resident and guest transport. LSV certified — street legal on roads up to 35 mph. |
| ⛳ Golf Courses | 4+0 Layout | Four golfers, one cart, two bag racks. Improves course efficiency and reduces fleet size. |
| 🏢 Commercial Shuttles | 4+0 Layout | Employee commutes, airport transfers, campus transport. Efficient passenger movement with low operating cost and zero emissions. |
| 🎉 Special Events | 2+2 Layout | Weddings, celebrations, event shuttles. Face-to-face design feels more welcoming — perfect for VIP reception and group photos. |
| 🏫 Campuses & Parks | 4+0 or 2+2 | University campuses, large parks, exhibition centers. Flexible configurations for different passenger volumes. Quiet and eco-friendly. |
Make It Yours – Full Customization
Logo
Silk screen or metal badge (front, sides, rear, steering wheel)one designs
Colors
Any Pantone color, metallic finishes, two-tone designs
Seats
Custom color, material (vinyl/leather/fabric), stitching
Accessories
Roof color, windshield type, wheel style, light kits
Modifications
Extended chassis, cargo bed, patrol lights, medical conversions
Fast Delivery & Local Support
Fast Delivery & Local Support
🇺🇸 US Warehouse – Popular models and parts stocked in the US
🚚 Fast Delivery – 3-7 business days for in-stock items
🔧 Parts Support – 2-5 business days from US warehouse
🛡️ 5-Year Battery Warranty – Full replacement
📞 US-Based Support – English-speaking team, 24/7 response
